This is Ortha from the Eurofurence 23 puppet show: “The Skies of Astar” (an almost 3-hour amateur live show with took place in the Estrel Hotel, Berlin, Germany, 19th August 2017). She is a giant 4-legged puppet with foldable wings, that is played by 2-6 puppeteers (depending on what features are used). She can be carried by one puppeteer, put on a rolling rig or be lifted by two ropes. It took almost every weekend from January to July 2017 to build her - with usually 2-4 people working on it. I did most of the work on the head - making a 3d-model, 3d-printing it, building all the Bowden cable animatronics. Ortha is about 2.6meters long, weighs 14.98kg.

Her features include:

  • 3d-printed head (PLA) Bowden-cable controlled animatronics (eyelids, ears, mouth, head-tilt front/back)
  • foldable wings (each wing has three segments - the feathers of the second segment tilt when the wing closes) with removable rods and magnetic connectors on the body (to keep them in place in the folded position)
  • control-rod for the head with 3d-printed levers, grips and battery holder
  • blue LED-lights in the eyes (with a switch on the control-rod)
  • movable eyelids
  • folding ears
  • movable lower-jaw
  • tiltable head
  • flexible neck and tail
  • fully articulated front-legs
  • movable back legs
  • front-paws with inbuilt gloves for the puppeteer
  • back-paws with rods
  • inbuilt connectors that can be used to hold the weight of the puppet from above or below (14.98 kg)
  • a hand sewed fake-fur cover that was painted with UV-paints (4 colors sprayed on, rubbed in with gloves and details drawn with UV-markers)
How Ortha was made (blog-post with many pictures): https://tioh.livejournal.com/131664.html









Tioh

Active Member
Joined
Jan 29, 2014
Messages
49
Reaction score
57
Orthas species was invented for the story. She's some kind of winged fantasy creature.


monkeyjb1988

Active Member
Joined
Jun 13, 2008
Messages
45
Reaction score
11




This is Ortha from the Eurofurence 23 puppet show: “The Skies of Astar” (an almost 3-hour amateur live show with took place in the Estrel Hotel, Berlin, Germany, 19th August 2017). She is a giant 4-legged puppet with foldable wings, that is played by 2-6 puppeteers (depending on what features are used). She can be carried by one puppeteer, put on a rolling rig or be lifted by two ropes. It took almost every weekend from January to July 2017 to build her - with usually 2-4 people working on it. I did most of the work on the head - making a 3d-model, 3d-printing it, building all the Bowden cable animatronics. Ortha is about 2.6meters long, weighs 14.98kg.

Her features include:

  • 3d-printed head (PLA) Bowden-cable controlled animatronics (eyelids, ears, mouth, head-tilt front/back)
  • foldable wings (each wing has three segments - the feathers of the second segment tilt when the wing closes) with removable rods and magnetic connectors on the body (to keep them in place in the folded position)
  • control-rod for the head with 3d-printed levers, grips and battery holder
  • blue LED-lights in the eyes (with a switch on the control-rod)
  • movable eyelids
  • folding ears
  • movable lower-jaw
  • tiltable head
  • flexible neck and tail
  • fully articulated front-legs
  • movable back legs
  • front-paws with inbuilt gloves for the puppeteer
  • back-paws with rods
  • inbuilt connectors that can be used to hold the weight of the puppet from above or below (14.98 kg)
  • a hand sewed fake-fur cover that was painted with UV-paints (4 colors sprayed on, rubbed in with gloves and details drawn with UV-markers)
How Ortha was made (blog-post with many pictures): https://tioh.livejournal.com/131664.html







SO... FREAKIN'... COOL!!!! Great puppets all around :smile:


Tioh

Active Member
Joined
Jan 29, 2014
Messages
49
Reaction score
57
A friend of mine wants to build a smaller version of Ortha (about half scale). I adjusted my 3d-model for hand puppet use (the original head base was made for external cable control). I also made a new 3d-model for the teeth and ears - because I do not have the time to make them by hand. The head base was printed with PLA filament, the teeth and ears were printed with flexible TPU filament. I attached the parts with Blackmorph.



The head has one new feature that the original did not have: the eyes can pan left to right. Eyelids and ears have attachment points for Bowden cables or servo motors. The eyes were 3d-printed with black UV resin. The moveable eyelids were printed with PLA.



Tioh

Active Member
Joined
Jan 29, 2014
Messages
49
Reaction score
57
I connected the bicycle brake cables for the movable eyelids, and ears - they are controlled by pushing/pulling at the end of a cable.
